Environmental | ||
Formaldehyde Emission(In air) | EN 14041:2004 | Pass – ≤0.08mg/m³ |
ASTM D6007-14 | ND – Not Detected | |
Phthalates Content | EN 14372: 2004 | ND – Not Detected |
Migration of certain elements | EN71-3:2013+A1:2014 | ND – Not Detected |
Formaldehyde Acetaldehyde TVOC |
Floor Score Indoor Air Quality | Pass – 3.69ug/m2-h |
SCS-FS-06767 | Pass – 2.69ug/m2-h | |
Pass – 178.6ug/m2-h |
Testing | ||
Dimensional Stability | Transverse – 80℃ | Pass – 0.01% |
Longitudinal – 80℃ | Pass – 0.04% | |
Curling | Pass – 0.01mm | |
Residual Indentation | ASTM F1914 | Pass – Avg ≤ 1.0%,Max 1.2% |
Peel Resistance | EN ISO 24345:2012 | Pass – 145N/5cm |
Impact Insulation Class (IIC ) | ASTM E492-09 / ASTM E989-06 | 57dB |
Sound Transmission Class (STC) | ASTM E90-09 / ASTM E413-16 | 51dB |
Reaction To Fire | EN 13501-1:2007 | Bfl-s1 |
Critical Flux | EN ISO 9239-1 | ≥ 11.1kW/m² |
Smoke | 139.1%×minutes | |
Abrasion Resistance | EN660-2:1999 & EN649:2011 | 1.4mm³/100 Revolutions |
Wear Group T | ||
Castor Chair Test | EN 425:2002 | Pass – No Damage |
Locking Strength | Unclick System | Pass – 262 & 269 N/5cm |
Scratch Performance | Pass – 2800g | |
Resistance To Chemicals | ASTM F925-13 | Pass – Not Affected |
Thermal Conductivity | EN 12667:2001 | Pass – 0.122 W/(m·K) |
Water Tightness | EN 13553:2017 | Pass – No Sign |
Dynamic Coefficient of Friction | EN 13893:2002 | Pass – Class DS |
